Ultrasonic Turntable Welding Machine

Frequency: 15KHZ-20KHZ

Power: 2000W-3500W

Body weight: 150KG
Signal processing: 485

Inquire Now Next Product

Functions and Features

The digital circuit system automatically tracks and locks the frequency.

The dual welding modes ensure high consistency, efficiency and stability in welding.

The independently developed operating system enables visual operation and control.

Horizontal adjustment meets the requirements of on-site welding operations.

Easy to integrate into automated production lines, reducing costs and increasing efficiency.

The frequency amplitude setting is adjustable from 10% to 100%.

Amplitude management, quality management, data management and safety management.

Meet the needs of automated production lines and reduce labor.

Equipment Parameters

Frequency	15KHZ-20KHZ
Power	2000W-3500W
Air Pressure	0.1-1.0MPA
Input Voltage	AC220V±10V
Welding Head Stroke	75mm
Machine Body Size	8507001950mm
Generator Size	400240110mm
Welding Mode	me/energy
Quality Management	Amplitude/Quality/Data/Safety Management
Body Weight	150KG
Working Mode	button/external control mode
Generator Circuit	digital intelligent automatic frequency tracking,
Signal Processing	485
Oscillation Time	0.01-9.99S
Frame	Round column
Language	English
Safety Management	password protection
Operation Interface	7-inch touch screen (Kunlun Tongtai)
Driving Method	pneumatic

Application Industry

Automotive industry: It can be used for welding automotive interior parts, exterior parts, engine compartment components, etc., such as the welding of parts like car lights, bumpers, instrument panels, and door interiors.
Plastic industry: It is widely used in the assembly of toys, the bonding of stationery, the welding of home appliance casings, the packaging of plastic casings for electronic products, etc.
Medical industry: It is often used for welding medical components, medical packaging, medical and health products, wound healing materials, etc., such as the welding of medical filters, syringes, medicine bottle packaging and so on.

Packaging industry: It can realize the sealing and welding of food packaging, cosmetics packaging, daily necessities packaging, etc., which can not only ensure the sealing of the packaging, but also make the packaging look beautiful.
