High-Power Ultrasonic Welding

Frequency: 15KHZ

Power: 4500W

Body weight: 245KG
Signal processing: 485/232

Inquire Now Next Product

Application industry

Automotive industry

It can be used for welding automotive interior parts, exterior parts, engine compartment components, etc., such as the welding of parts like car lights, bumpers, instrument panels, and door interiors.

Plastic industry

It is widely used in the assembly of toys, the bonding of stationery, the welding of home appliance casings, the packaging of plastic casings for electronic products, etc.

Medical industry

Independently developed operating system enables visual operation and control

Packaging industry

It can realize the sealing and welding of food packaging, cosmetics packaging, daily necessities packaging, etc., which can not only ensure the sealing of the packaging, but also make the packaging look beautiful.

Equipment Parameters

Frequency	15KHZ
Power	4500W
Air pressure	0.1-1.0MPA
Input voltage	AC220V-240V
Welding head stroke	100mm
Machine body size	9007501950mm
Generator size	400240120mm
Welding mode	time/energy/external control
Quality Management	time/energy/power
Body weight	245KG
Working mode	two-hand button start
Generator circuit	digital intelligent automatic frequency tracking
Signal processing	485/232
Oscillation time	0.01-9.99S
frame	square column,
System language	Customizable
Safety management	password protection
Cooling method	air cooling
Driving mode	pneumatic

Functions and Features

1.Digital circuit system with automatic frequency tracking and automatic frequency locking
2.Dual welding modes ensure high welding consistency, efficiency and stability
3.Independently developed operating system enables visual operation and control
4.Horizontal adjustment meets on-site welding operation requirements
5.Easy to integrate into automated production lines, reducing costs and increasing efficiency
6.Frequency amplitude setting is adjustable from 10% to 100%
7.Amplitude management, quality management, data management, safety management
8.A wide range of models cover frequencies from 15k power from 4500W .
