6500W Ultrasonic Welding Machine

Frequency: 15KHZ

Power: 2000W-3500W

Body weight: 275KG
Signal processing: 485/232

Inquire Now Next Product

Applications

Automotive/New Energy Industry

Used for welding tabs, battery modules, lightweight materials, ADAS sensors, charging pile wire harnesses, window motors and airbag components

3C Electronics Industry

Capable of welding tabs of mobile phone and TWS earphone batteries, micro sensors, connectors, as well as plastic casings of Bluetooth headsets and smart key fobs

Precision Electrical and Electronic Industry

Suitable for welding motors and controllers, power adapters, smart home sensors, industrial wire harnesses, energy storage and high-voltage wire harnesses

Medical Equipment Industry

Applied to the welding of implantable medical devices, disposable medical consumables, medical electronics and precision instruments

Equipment Parameters

Frequency	15KHZ
Power	4500W-6500W
Air Pressure	0.1-1.0MPA
Input Voltage	AC220V±10V
Welding Head Stroke	100mm
Machine Body Size	8009301900mm
Generator Size	380290110mm
Welding Mode	ime/energy/ external control
Quality Management	Amplitude/Quality/Data/Safety Management
Body Weight	275KG
Working Mode	button/external control mode
Generator Circuit	digital intelligent automatic frequency tracking,
Signal Processing	485/232
Oscillation Time	0.01-9.99S
Frame	square column
Language	English
Safety Management	password protection
Operation Interface	7-inch touch screen (Kunlun Tongtai)
Driving Method	pneumatic

Advantages

1.Digital circuit system with automatic frequency tracking and automatic frequency locking
2.Dual welding modes ensure high welding consistency, efficiency and stability
3.Independently developed operating system enables visual operation and control
4.Horizontal adjustment meets on-site welding operation requirements
5.Easy to integrate into automated production lines, reducing costs and increasing efficiency
6.Frequency amplitude setting is adjustable from 10% to 100%
7.Amplitude management, quality management, data management, safety management
8.A wide range of models cover frequencies from 15k power from 3500W .
