Frequency: 15KHZ/20KHZ
Power: 3000W-400W
Body weight: 90KG
Control system: servo control
Product Descriptions
This ultrasonic servo welding machine integrates a variety of advanced welding control technologies and complies with European CE safety standards to ensure safe and regulatory operation. It is equipped with a full closed-loop servo stroke control system (with a precision of 0.01mm), which can eliminate mechanical errors and achieve high-precision welding. It also features a fault self-inspection function that can comprehensively detect the switches of the machine body, feedback faults in a timely manner to reduce maintenance costs. The column adopts a high-strength slide rail design to ensure welding strength and high precision of mechanical movements. In terms of data management, it has built-in storage and transmission functions, supports intelligent tracking, and can seamlessly connect to the MES system (customized) and PC kits, facilitating data-driven production management.
Advantages
Plastic products industry
Suitable for secondary connection of thermoplastic plastics such as folders, photo albums, folding boxes, and PP hollow boards. With reasonable design of workpieces and interfaces, watertight and airtight effects can be achieved
Medical equipment industry
Widely used in the manufacturing of surgical gowns, medical gloves, syringes, pipe connectors, and skin expanders. The entire welding process does not rely on glue or chemical solvents, with zero VOC emissions, meeting the strict environmental and hygiene standards of the medical device industry
Liquid filter industry
Liquid filters need to be pressure-resistant and leak-proof. Ultrasonic servo welding machines achieve reliable connections through precise control, effectively meeting relevant needs
3C electronics industry
Commonly used for welding plastic components such as smartphone cases. Parameters can be flexibly adjusted to adapt to different materials and thicknesses, ensuring the strength and appearance quality of the welded joints
Equipment Parameters
| Model | Servo welding machine |
| Intelligent management | Amplitude/Quality/Recipe/Data/Safety management |
| Power | 3000W/4000W |
| Body weight | 90KG |
| frequency | 15KHZ/20KHZ |
| Operation interface | 10-inch touch screen |
| Input voltage | AC220V |
| working mode | button/external control mode |
| Language | English |
| body size | 8000x400x1385mm |
| working mode | button/external control mode |
| Z-axis precision | 0.01mm |
| functional features | data storage/transmission/EMS system/welding records |
| welding mode | manual/time/energy/absolute stroke/relative stroke/multi-stroke/ultrasonic stop vibration/Xn mode |
Application Industry
1. Intelligent stepped amplitude
2. Digital visual automatic frequency tracking system
3. Horizontal adjustment for quick replacement of upper and lower molds
4. Precision sliding slider and linear guide, with small error
5. Servo drive combined with servo motor, variable speed lifting
6 .trigger modes and 3 welding modes
7.ypes of quality monitoring to ensure welding quality
8.New IoT control system
9.Can be connected to MES system (customized) for data upload
10.Fault self-inspection and abnormality monitoring
11.Human-machine interface, with welding record query/storage/export
