3500 Ultrasonic Plastic Welding Machine

Frequency: 15KHZ-20KHZ

Power: 2000W-3500W

Body weight: 140KG
Signal processing: 485/232

Inquire Now Next Product

Application Industry

Automotive industry

It can be used for welding automotive interior parts, exterior parts, engine compartment components, etc., such as the welding of parts like car lights, bumpers, instrument panels, and door interiors

Plastic industry

It is widely used in the assembly of toys, the bonding of stationery, the welding of home appliance casings, the packaging of plastic casings for electronic products, etc

Medical industry

Independently developed operating system enables visual operation and control

Packaging industry

It can realize the sealing and welding of food packaging, cosmetics packaging, daily necessities packaging, etc., which can not only ensure the sealing of the packaging, but also make the packaging look beautiful

Equipment Parameters

Frequency	15KHZ-20KHZ
Power	2000W-3500W
Air Pressure	0.1-1.0MPA
Input Voltage	AC220V-240V
Welding Head Stroke	75mm
Machine Body Size	6006001850mm
Generator Size	400240120mm
Welding Mode	ime/energy
Quality Management	time/energy/power
Body Weight	140KG
Working Mode	dual-twist start
Generator Circuit	digital intelligent automatic frequency tracking
Signal Processing	485/232
Oscillation Time	0.01-9.99S
Frame	Round column
Language	English
Safety Management	password protection
Operation Interface	4.3-inch touch screen (Kunlun Tongtai)
Driving Method	pneumatic

Functions and Features

1.Digital circuit system with automatic frequency tracking and automatic frequency locking

2.Dual welding modes ensure high welding consistency, efficiency and stability
3.Independently developed operating system enables visual operation and control
4.Horizontal adjustment meets on-site welding operation requirements
5.Easy to integrate into automated production lines, reducing costs and increasing efficiency
6.Frequency amplitude setting is adjustable from 10% to 100%
7.Amplitude management, quality management, data management, safety management
8.A wide range of models cover frequencies from 15k power from 4500W .
