3200W Ultrasonic Plastic Welding Machine

Frequency: 15KHZ-20KHZ

Power: 2000W-3500W

Body weight: 90KG
Signal processing: 485/232

Inquire Now Next Product

Functions and Features

The digital circuit system automatically tracks and locks the frequency.

Four-column motor lifting, dual welding modes ensure high consistency, efficiency and stability in welding.

The independently developed operating system enables visual operation and control.

Horizontal adjustment meets the requirements of on-site welding operations.

Easy to integrate into automated production lines, reducing costs and increasing efficiency.

The frequency amplitude setting is adjustable from 10% to 100%.

Amplitude management, quality management, data management, safety management.

A wide range of models cover frequencies from 15kHz to 20kHz and power from 2000W to 3500W.

Equipment Parameters

Frequency	15KHZ-20KHZ
Power	2000W-3500W
Air pressure	0.1-1.0MPA
Input voltage	AC220V-240V
Welding head stroke	75mm
Machine body size	7606001600mm
Generator size	400240120mm
Welding mode	time/energy/external control,
Quality Management	Amplitude/Quality/Data/Safety Management
Body weight	90KG
Working mode	Raster induction start-up
Generator circuit	digital intelligent automatic frequency tracking
Signal processing	485/232
Oscillation time	0.01-9.99S
frame	Four columns
System language	Customizable
Safety management	password protection
Cooling method	air cooling
Driving mode	External control

Application Industry

Automotive industry: It can be used for welding automotive interior parts, exterior parts, engine compartment components, etc., such as the welding of parts like car lights, bumpers, instrument panels, and door interiors.
Zinc die-casting industry: Used for connecting zinc alloy auto parts, locks and bathroom accessories, with no solder pollution and high efficiency.

Ceramic industry: Used for connecting ceramic substrates with metal pins, sensor packaging, and splicing of cutters and bearings, with high surface flatness after welding.

Glass industry: Used for connecting optical instruments, medical devices and electronic glass, featuring low-temperature welding, good sealing performance and no damage to optical properties.
