Ultrasonic Plastic Welding Machine
15-20KHZ Ultrasonic Welding Machine
15-20KHZ Ultrasonic Welding Machine

15-20KHZ Ultrasonic Welding Machine

Frequency: 15KHZ-20KHZ

Power: 2000W-3500W

Body weight: 65KG
Signal processing: 485





Application Industry

Automotive/New Energy Industry

Automotive/New Energy Industry

Used for welding tabs, battery modules, lightweight materials, ADAS sensors, charging pile wire harnesses, window motors and airbag components

3C Electronics Industry

3C Electronics Industry

Capable of welding tabs of mobile phone and TWS earphone batteries, micro sensors, connectors, as well as plastic casings of Bluetooth headsets and smart key fobs

Precision Electrical and Electronic Industry

Precision Electrical and Electronic Industry

Suitable for welding motors and controllers, power adapters, smart home sensors, industrial wire harnesses, energy storage and high-voltage wire harnesses

Medical Equipment Industry

Medical Equipment Industry

Applied to the welding of implantable medical devices, disposable medical consumables, medical electronics and precision instruments

Equipment Parameters

Frequency15KHZ-20KHZ
Power2000W-3500W
Air Pressure0.1-1.0MPA
Input VoltageAC220V±10V
Welding Head Stroke75mm
Machine Body Size600*400*1050mm
Generator Size400*240*120mm
Welding Modeime/energy
Quality ManagementAmplitude/Quality/Data/Safety Management
Body Weight65KG
Working ModeDouble-twist start
Generator Circuitdigital intelligent automatic frequency tracking,
Signal Processing485
Oscillation Time0.01-9.99S
Framesquare column
System LanguageEnglish
Safety Managementpassword protection
Operation Interface4.3-inch touch screen (Kunlun Tongtai)
Driving Methodpneumatic


Functions and Features

1.Digital circuit system with automatic frequency tracking and automatic frequency locking
2.Dual welding modes ensure high welding consistency, efficiency and stability
3.Independently developed operating system enables visual operation and control
4.Horizontal adjustment meets on-site welding operation requirements
5.Easy to integrate into automated production lines, reducing costs and increasing efficiency
6.Frequency amplitude setting is adjustable from 10% to 100%
7.Amplitude management, quality management, data management, safety management
8.A wide range of models cover frequencies from 15k power from 3500W .
