Maximum load: 6kg.
Repeat positioning accuracy: ±0.02mm.
Protection class: IP40.
Body weight: 180kg.
Installation: floor-mounted, side-hung, overhead crane-mounted.
Product Descriptions
The small industrial robot is a desktop robotic arm designed for lightweight, precision tasks, offering high speed, flexibility, quick deployment, and energy efficiency. With a repeatability of ±0.02mm, it provides millimeter-level accuracy for operations such as sorting, assembly, and inspection of small, lightweight components. Featuring a maximum payload of 4-6kg ,it is ideal for use in confined spaces and applications including 3C electronics, material handling, painting, part picking, packaging, assembly, and dispensing.
Specifications
| Small industrial robot | DDB04D | DDB1400P | |
| Action area | Maximum elongation | 541(mm) | 1402(mm) |
| Minimum elongation | 119(mm) | 399(mm) | |
| Before and after | 422(mm) | 1003(mm) | |
| Maximum payload | 4KG | 6KG | |
| Body weight | 26KG | 180KG | |
| nstallation | IP40 | IP50 | |
| Range of motion | J1 | ±170 | ±170 |
| J2 | -145/+90 | -155/+100 | |
| J3 | -70/+190 | -80/+165 | |
| J4 | ±190 | ±180 | |
| J5 | -30/+210 | -50/+225 | |
| J6 | ±360 | ±270 | |
| Maximum instantaneous velocity | J1 | 480 | 190 |
| J2 | 460 | 190 | |
| J3 | 520 | 190 | |
| J4 | 560 | 370 | |
| J5 | 560 | 370 | |
| J6 | 900 | 600 | |
