Positioning accuracy: ±0.06mm.
Protection grade: IP50.
Main body weight: 280kg
Installation: ground, side hanging, ceiling hanging.
Maximum Load: 20kg.
Product Descriptions
This 20kg collaborative robot is specifically designed for medium-load applications in industrial automation. Integrated with advanced control systems and high-precision sensors, it achieves millimeter-level repeat positioning accuracy. Featuring high movement speed and fast response characteristics, it significantly enhances production efficiency. Its optimized mechanical structure offers excellent rigidity and operational stability, ensuring smooth movement and precise positioning even under full load, effectively suppressing vibration and offset to guarantee operational reliability and consistency.
Specifications
| Basic Parameters | ||
| Action area | Maximum elongation | 1710(mm) |
| Minimum elongation | 467(mm) | |
| Before and after | 1243(mm) | |
| Range of motion | J1 | ±170 |
| J2 | -125/+105 | |
| J3 | -70/+120 | |
| J4 | ±180 | |
| J5 | -45/+225 | |
| J6 | ±270 | |
| Maximum instantaneous velocity | J1 | 195 |
| J2 | 190 | |
| J3 | 180 | |
| J4 | 400 | |
| J5 | 400 | |
| J6 | 600 | |
